12000bph-3-in-1-carbonated-soft-drink-filling-machine - Reytop
12000bph-3-in-1-carbonated-soft-drink-filling-machine

12000bph-3-in-1-carbonated-soft-drink-filling-machine

Model: DXFG40-40-10
Capacity: 10000~12000 Bottles Per Hour
Bottle Sizes: 250ml ~2L
Function: Washing, Filling, Capping Machine
Product Description

This Machine mainly used in the Carbonated beverage filling operations, the three function of bottle washing, filling and capping are composed in one body of the machine, the whole process is automatic, it is conveniently turnked to adjust the machine to fill various types of bottles, the filling operation is faster and more stable due to the advanced filling valve technology. The famous brand programeed controller (PLC) is adopted to control the machine runs automatically. It is a ideal perferred equipment for beverage makers.

Get A Free Quote Now

This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.

Products Details

iPack
iPack
iPack
iPack
iPack
iPack

Technical Parameter

Model DXFG40-40-10
Capacity: (500ML) 10000~12000 bottles/hour
Suitable bottle shapes 10000~12000 bottles/hour
Bottle diameter 50~115mm
Bottle height 120~320mm
Compressor air 0.3~0.7Mpa
Washing medium Pure Water
Filling type Isobaric filling
Application Carbonated drink / Sparkling water
Main motor power 5.5kW
Overall dimensions 4350*3300*2700mm
Weight 9500kg
